Wheatley, 5P-323, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 1¼" |
| Maximum Plunger Diameter: | 2½" |
| Stroke length: | 3⅛" |
| Maximum Working Pressure: | 3,260 PSI |
| Rod/Piston Load: | 4000lb |
| Gallons per Minute: | 161.0 |
| Barrels per Day: | 5520 |
| Brake Horse Power: | 88.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 200 RPM | 350 RPM | 500 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| 5P-323 | 2.500 | 4.9087 | 11.384 | 0.3320 | 815 | 569 | 17 | 2277 | 66 | 3984 | 116 | 5692 | 166 |
| 2.375 | 4.4301 | 10.274 | 0.2997 | 903 | 514 | 15 | 2055 | 60 | 3596 | 105 | 5137 | 150 | |
| 2.250 | 3.9761 | 9.221 | 0.2689 | 1006 | 461 | 13 | 1844 | 54 | 3227 | 94 | 4611 | 134 | |
| 2.125 | 3.5466 | 8.225 | 0.2399 | 1128 | 411 | 12 | 1645 | 48 | 2879 | 84 | 4112 | 120 | |
| 2.000 | 3.1416 | 7.286 | 0.2125 | 1273 | 364 | 11 | 1457 | 42 | 2550 | 74 | 3643 | 106 | |
| 1.875 | 2.7612 | 6.403 | 0.1868 | 1449 | 320 | 9 | 1281 | 37 | 2241 | 65 | 3202 | 93 | |
| 1.750 | 2.4053 | 5.578 | 0.1627 | 1663 | 279 | 8 | 1116 | 33 | 1952 | 57 | 2789 | 81 | |
| 1.625 | 2.0739 | 4.810 | 0.1403 | 1929 | 240 | 7 | 962 | 28 | 1683 | 49 | 2405 | 70 | |
| 1.500 | 1.7671 | 4.098 | 0.1195 | 2264 | 205 | 6 | 820 | 24 | 1434 | 42 | 2049 | 60 | |
| 1.375 | 1.4849 | 3.444 | 0.1004 | 2694 | 172 | 5 | 689 | 20 | 1205 | 35 | 1722 | 50 | |
| 1.250 | 1.2272 | 2.846 | 0.0830 | 3259 | 142 | 4 | 569 | 17 | 996 | 29 | 1423 | 42 | |
