Wheatley, P100-A (11D-2M), Duplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | duplex |
| Minimum Plunger Diameter: | 1⅛" |
| Maximum Plunger Diameter: | 1¾" |
| Stroke length: | 2 3/16" |
| Maximum Working Pressure: | 2,042 PSI |
| Rod/Piston Load: | 2030lb |
| Gallons per Minute: | 18.2 |
| Barrels per Day: | 624 |
| Brake Horse Power: | 11.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 400 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| P100-A 11D-2M | 1.750 | 2.4053 | 1.562 | 0.0456 | 844 | 78 | 2 | 234 | 7 | 390 | 11 | 547 | 16 | 625 | 18 |
| 1.625 | 2.0739 | 1.347 | 0.0393 | 979 | 67 | 2 | 202 | 6 | 337 | 10 | 471 | 14 | 539 | 16 | |
| 1.500 | 1.7671 | 1.147 | 0.0335 | 1149 | 57 | 2 | 172 | 5 | 287 | 8 | 402 | 12 | 459 | 13 | |
| 1.375 | 1.4849 | 0.964 | 0.0281 | 1367 | 48 | 1 | 145 | 4 | 241 | 7 | 337 | 10 | 386 | 11 | |
| 1.250 | 1.2272 | 0.797 | 0.0232 | 1654 | 40 | 1 | 120 | 3 | 199 | 6 | 279 | 8 | 319 | 9 | |
| 1.125 | 0.9940 | 0.645 | 0.0188 | 2042 | 32 | 1 | 97 | 3 | 161 | 5 | 226 | 7 | 258 | 8 | |
