Wheatley, P200-B, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1⅛" |
| Maximum Plunger Diameter: | 1¾" |
| Stroke length: | 2 3/16" |
| Maximum Working Pressure: | 2,050 PSI |
| Rod/Piston Load: | 2030lb |
| Gallons per Minute: | 33.6 |
| Barrels per Day: | 1152 |
| Brake Horse Power: | 19.15 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 200 RPM | 350 RPM | 500 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| P200-B | 1.750 | 2.4053 | 2.343 | 0.0683 | 844 | 117 | 3 | 469 | 14 | 820 | 24 | 1171 | 34 |
| 1.625 | 2.0739 | 2.020 | 0.0589 | 979 | 101 | 3 | 404 | 12 | 707 | 21 | 1010 | 29 | |
| 1.500 | 1.7671 | 1.721 | 0.0502 | 1149 | 86 | 3 | 344 | 10 | 602 | 18 | 861 | 25 | |
| 1.375 | 1.4849 | 1.446 | 0.0422 | 1367 | 72 | 2 | 289 | 8 | 506 | 15 | 723 | 21 | |
| 1.250 | 1.2272 | 1.195 | 0.0349 | 1654 | 60 | 2 | 239 | 7 | 418 | 12 | 598 | 17 | |
| 1.125 | 0.9940 | 0.968 | 0.0282 | 2042 | 48 | 1 | 194 | 6 | 339 | 10 | 484 | 14 | |
