Wheatley, HP360-XL (308T-7XL), Triplex, Plunger Pump
- 308 horsepower 7" stroke horizontal triplex single acting plunger pump
- Available in three fluid end materials
- Pump speeds up to 265 RPM
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 4½" |
| Maximum Plunger Diameter: | 5¾" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 1,220 PSI |
| Rod/Piston Load: | 19400lb |
| Gallons per Minute: | 636.7 |
| Barrels per Day: | 21830 |
| Brake Horse Power: | 308.0 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 265 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP360-XL 308T-7XL | 5.750 | 25.9672 | 82.382 | 2.4028 | 747 | 4119 | 120 | 12357 | 360 | 20596 | 601 | 21831 | 637 |
| 5.625 | 24.8505 | 78.839 | 2.2995 | 781 | 3942 | 115 | 11826 | 345 | 19710 | 575 | 20892 | 609 | |
| 5.500 | 23.7583 | 75.374 | 2.1984 | 817 | 3769 | 110 | 11306 | 330 | 18844 | 550 | 19974 | 583 | |
| 5.375 | 22.6906 | 71.987 | 2.0996 | 855 | 3599 | 105 | 10798 | 315 | 17997 | 525 | 19077 | 556 | |
| 5.250 | 21.6475 | 68.678 | 2.0031 | 896 | 3434 | 100 | 10302 | 300 | 17169 | 501 | 18200 | 531 | |
| 5.125 | 20.6290 | 65.446 | 1.9088 | 940 | 3272 | 95 | 9817 | 286 | 16362 | 477 | 17343 | 506 | |
| 5.000 | 19.6350 | 62.293 | 1.8169 | 988 | 3115 | 91 | 9344 | 273 | 15573 | 454 | 16508 | 481 | |
| 4.875 | 18.6655 | 59.217 | 1.7272 | 1039 | 2961 | 86 | 8883 | 259 | 14804 | 432 | 15693 | 458 | |
| 4.750 | 17.7205 | 56.219 | 1.6397 | 1095 | 2811 | 82 | 8433 | 246 | 14055 | 410 | 14898 | 435 | |
| 4.625 | 16.8002 | 53.299 | 1.5546 | 1155 | 2665 | 78 | 7995 | 233 | 13325 | 389 | 14124 | 412 | |
| 4.500 | 15.9043 | 50.457 | 1.4717 | 1220 | 2523 | 74 | 7569 | 221 | 12614 | 368 | 13371 | 390 | |
- Cast iron power frame
- Ductile Iron crankshaft
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Cast iron crossheads with upper/lower oil grooves
- Stainless steel extension rods
- Internal pressure lubrication
- Bolted Type Valve Covers
- Removable Stuffing Boxes & Glands
- Plungers - Ceramic, or Tungsten Coated Â
