Gaso, T165-3, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2" |
| Maximum Plunger Diameter: | 2¾" |
| Stroke length: | 5" |
| Maximum Working Pressure: | 2,875 PSI |
| Rod/Piston Load: | 10200lb |
| Gallons per Minute: | 142.0 |
| Barrels per Day: | 4869 |
| Brake Horse Power: | 159.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 370 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T165-3 | 2.750 | 5.9396 | 13.224 | 0.3857 | 1717 | 661 | 19 | 1984 | 58 | 3306 | 96 | 4628 | 135 | 4893 | 143 |
| 2.625 | 5.4119 | 12.049 | 0.3514 | 1885 | 602 | 18 | 1807 | 53 | 3012 | 88 | 4217 | 123 | 4458 | 130 | |
| 2.500 | 4.9087 | 10.929 | 0.3187 | 2078 | 546 | 16 | 1639 | 48 | 2732 | 80 | 3825 | 112 | 4044 | 118 | |
| 2.375 | 4.4301 | 9.863 | 0.2877 | 2302 | 493 | 14 | 1480 | 43 | 2466 | 72 | 3452 | 101 | 3649 | 106 | |
| 2.250 | 3.9761 | 8.852 | 0.2582 | 2565 | 443 | 13 | 1328 | 39 | 2213 | 65 | 3098 | 90 | 3275 | 96 | |
| 2.125 | 3.5466 | 7.896 | 0.2303 | 2875 | 395 | 12 | 1184 | 35 | 1974 | 58 | 2764 | 81 | 2922 | 85 | |
| 2.000 | 3.1416 | 6.994 | 0.2040 | 2875 | 350 | 10 | 1049 | 31 | 1749 | 51 | 2448 | 71 | 2588 | 75 | |
