Gaso, T200-4, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 3¼" |
| Maximum Plunger Diameter: | 4" |
| Stroke length: | 5" |
| Maximum Working Pressure: | 1,590 PSI |
| Rod/Piston Load: | 13200lb |
| Gallons per Minute: | 293.8 |
| Barrels per Day: | 10073 |
| Brake Horse Power: | 200.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 360 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T200-4 | 4.000 | 12.5664 | 27.977 | 0.8160 | 1050 | 1399 | 41 | 4197 | 122 | 6994 | 204 | 9792 | 286 | 10072 | 294 |
| 3.875 | 11.7932 | 26.256 | 0.7658 | 1119 | 1313 | 38 | 3938 | 115 | 6564 | 191 | 9190 | 268 | 9452 | 276 | |
| 3.750 | 11.0447 | 24.589 | 0.7172 | 1195 | 1230 | 36 | 3688 | 108 | 6147 | 179 | 8606 | 251 | 8852 | 258 | |
| 3.625 | 10.3206 | 22.977 | 0.6702 | 1279 | 1149 | 34 | 3447 | 101 | 5744 | 168 | 8042 | 235 | 8272 | 241 | |
| 3.500 | 9.6211 | 21.420 | 0.6247 | 1372 | 1071 | 31 | 3213 | 94 | 5355 | 156 | 7497 | 219 | 7711 | 225 | |
| 3.375 | 8.9462 | 19.917 | 0.5809 | 1475 | 996 | 29 | 2988 | 87 | 4979 | 145 | 6971 | 203 | 7170 | 209 | |
| 3.250 | 8.2958 | 18.469 | 0.5387 | 1590 | 923 | 27 | 2770 | 81 | 4617 | 135 | 6464 | 189 | 6649 | 194 | |
