Wheatley, HP250-AM, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2" |
| Maximum Plunger Diameter: | 3¾" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 3,680 PSI |
| Rod/Piston Load: | 11580lb |
| Gallons per Minute: | 145.6 |
| Barrels per Day: | 4992 |
| Brake Horse Power: | 182.7 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 265 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP250-AM | 3.750 | 11.0447 | 35.040 | 1.0220 | 1048 | 1752 | 51 | 5256 | 153 | 8760 | 255 | 9286 | 271 |
| 3.500 | 9.6211 | 30.523 | 0.8903 | 1204 | 1526 | 45 | 4579 | 134 | 7631 | 223 | 8089 | 236 | |
| 3.250 | 8.2958 | 26.319 | 0.7676 | 1396 | 1316 | 38 | 3948 | 115 | 6580 | 192 | 6974 | 203 | |
| 3.000 | 7.0686 | 22.425 | 0.6541 | 1638 | 1121 | 33 | 3364 | 98 | 5606 | 164 | 5943 | 173 | |
| 2.750 | 5.9396 | 18.844 | 0.5496 | 1950 | 942 | 27 | 2827 | 82 | 4711 | 137 | 4994 | 146 | |
| 2.500 | 4.9087 | 15.573 | 0.4542 | 2359 | 779 | 23 | 2336 | 68 | 3893 | 114 | 4127 | 120 | |
| 2.250 | 3.9761 | 12.614 | 0.3679 | 2912 | 631 | 18 | 1892 | 55 | 3154 | 92 | 3343 | 97 | |
| 2.000 | 3.1416 | 9.967 | 0.2907 | 3680 | 498 | 15 | 1495 | 44 | 2492 | 73 | 2641 | 77 | |
