Wheatley, HP250-L, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 3" |
| Maximum Plunger Diameter: | 4" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 1,640 PSI |
| Rod/Piston Load: | 11580lb |
| Gallons per Minute: | 308.2 |
| Barrels per Day: | 10567 |
| Brake Horse Power: | 182.7 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 265 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP250-L | 4.000 | 12.5664 | 39.867 | 1.1628 | 922 | 1993 | 58 | 5980 | 174 | 9967 | 291 | 10565 | 308 |
| 3.875 | 11.7932 | 37.415 | 1.0913 | 982 | 1871 | 55 | 5612 | 164 | 9354 | 273 | 9915 | 289 | |
| 3.750 | 11.0447 | 35.040 | 1.0220 | 1048 | 1752 | 51 | 5256 | 153 | 8760 | 255 | 9286 | 271 | |
| 3.625 | 10.3206 | 32.743 | 0.9550 | 1122 | 1637 | 48 | 4911 | 143 | 8186 | 239 | 8677 | 253 | |
| 3.500 | 9.6211 | 30.523 | 0.8903 | 1204 | 1526 | 45 | 4579 | 134 | 7631 | 223 | 8089 | 236 | |
| 3.375 | 8.9462 | 28.382 | 0.8278 | 1294 | 1419 | 41 | 4257 | 124 | 7096 | 207 | 7521 | 219 | |
| 3.250 | 8.2958 | 26.319 | 0.7676 | 1396 | 1316 | 38 | 3948 | 115 | 6580 | 192 | 6974 | 203 | |
| 3.125 | 7.6699 | 24.333 | 0.7097 | 1510 | 1217 | 35 | 3650 | 106 | 6083 | 177 | 6448 | 188 | |
| 3.000 | 7.0686 | 22.425 | 0.6541 | 1638 | 1121 | 33 | 3364 | 98 | 5606 | 164 | 5943 | 173 | |
