Wheatley, HP250-M, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2" |
| Maximum Plunger Diameter: | 3" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 3,680 PSI |
| Rod/Piston Load: | 11580lb |
| Gallons per Minute: | 173.3 |
| Barrels per Day: | 5942 |
| Brake Horse Power: | 182.7 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 265 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP250-M | 3.000 | 7.0686 | 22.425 | 0.6541 | 1638 | 1121 | 33 | 3364 | 98 | 5606 | 164 | 5943 | 173 |
| 2.875 | 6.4918 | 20.596 | 0.6007 | 1784 | 1030 | 30 | 3089 | 90 | 5149 | 150 | 5458 | 159 | |
| 2.750 | 5.9396 | 18.844 | 0.5496 | 1950 | 942 | 27 | 2827 | 82 | 4711 | 137 | 4994 | 146 | |
| 2.625 | 5.4119 | 17.169 | 0.5008 | 2140 | 858 | 25 | 2575 | 75 | 4292 | 125 | 4550 | 133 | |
| 2.500 | 4.9087 | 15.573 | 0.4542 | 2359 | 779 | 23 | 2336 | 68 | 3893 | 114 | 4127 | 120 | |
| 2.375 | 4.4301 | 14.055 | 0.4099 | 2614 | 703 | 20 | 2108 | 61 | 3514 | 102 | 3725 | 109 | |
| 2.250 | 3.9761 | 12.614 | 0.3679 | 2912 | 631 | 18 | 1892 | 55 | 3154 | 92 | 3343 | 97 | |
| 2.125 | 3.5466 | 11.252 | 0.3282 | 3265 | 563 | 16 | 1688 | 49 | 2813 | 82 | 2982 | 87 | |
| 2.000 | 3.1416 | 9.967 | 0.2907 | 3680 | 498 | 15 | 1495 | 44 | 2492 | 73 | 2641 | 77 | |
