Wheatley, Q3150-H, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | ¾" |
| Maximum Plunger Diameter: | 1" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 10,000 PSI |
| Rod/Piston Load: | 6350lb |
| Gallons per Minute: | 26.2 |
| Barrels per Day: | 898 |
| Brake Horse Power: | 137.4 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 440 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| Q3150-H | 1.000 | 0.7854 | 2.040 | 0.0595 | 8085 | 102 | 3 | 306 | 9 | 510 | 15 | 714 | 21 | 898 | 26 |
| 0.875 | 0.6013 | 1.562 | 0.0456 | 10000 | 78 | 2 | 234 | 7 | 390 | 11 | 547 | 16 | 687 | 20 | |
| 0.750 | 0.4418 | 1.147 | 0.0335 | 10000 | 57 | 2 | 172 | 5 | 287 | 8 | 402 | 12 | 505 | 15 | |
