Wheatley, Q3150-M, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 1¾" |
| Maximum Plunger Diameter: | 2½" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 2,640 PSI |
| Rod/Piston Load: | 6350lb |
| Gallons per Minute: | 132.4 |
| Barrels per Day: | 4539 |
| Brake Horse Power: | 137.4 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 440 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| Q3150-M | 2.500 | 4.9087 | 12.750 | 0.3719 | 1294 | 637 | 19 | 1913 | 56 | 3188 | 93 | 4463 | 130 | 5610 | 164 |
| 2.375 | 4.4301 | 11.507 | 0.3356 | 1433 | 575 | 17 | 1726 | 50 | 2877 | 84 | 4027 | 117 | 5063 | 148 | |
| 2.250 | 3.9761 | 10.327 | 0.3012 | 1597 | 516 | 15 | 1549 | 45 | 2582 | 75 | 3615 | 105 | 4544 | 133 | |
| 2.125 | 3.5466 | 9.212 | 0.2687 | 1790 | 461 | 13 | 1382 | 40 | 2303 | 67 | 3224 | 94 | 4053 | 118 | |
| 2.000 | 3.1416 | 8.160 | 0.2380 | 2021 | 408 | 12 | 1224 | 36 | 2040 | 59 | 2856 | 83 | 3590 | 105 | |
| 1.875 | 2.7612 | 7.172 | 0.2092 | 2300 | 359 | 10 | 1076 | 31 | 1793 | 52 | 2510 | 73 | 3156 | 92 | |
| 1.750 | 2.4053 | 6.247 | 0.1822 | 2640 | 312 | 9 | 937 | 27 | 1562 | 46 | 2187 | 64 | 2749 | 80 | |
