Wheatley, Q3150-L, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 2¼" |
| Maximum Plunger Diameter: | 3" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 1,600 PSI |
| Rod/Piston Load: | 6350lb |
| Gallons per Minute: | 235.6 |
| Barrels per Day: | 8078 |
| Brake Horse Power: | 137.4 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 440 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| Q3150-L | 3.000 | 7.0686 | 18.360 | 0.5355 | 898 | 918 | 27 | 2754 | 80 | 4590 | 134 | 6426 | 187 | 8078 | 236 |
| 2.875 | 6.4918 | 16.862 | 0.4918 | 978 | 843 | 25 | 2529 | 74 | 4216 | 123 | 5902 | 172 | 7419 | 216 | |
| 2.750 | 5.9396 | 15.427 | 0.4500 | 1069 | 771 | 22 | 2314 | 67 | 3857 | 112 | 5400 | 157 | 6788 | 198 | |
| 2.625 | 5.4119 | 14.057 | 0.4100 | 1173 | 703 | 20 | 2109 | 61 | 3514 | 102 | 4920 | 143 | 6185 | 180 | |
| 2.500 | 4.9087 | 12.750 | 0.3719 | 1294 | 637 | 19 | 1913 | 56 | 3188 | 93 | 4463 | 130 | 5610 | 164 | |
| 2.375 | 4.4301 | 11.507 | 0.3356 | 1433 | 575 | 17 | 1726 | 50 | 2877 | 84 | 4027 | 117 | 5063 | 148 | |
| 2.250 | 3.9761 | 10.327 | 0.3012 | 1597 | 516 | 15 | 1549 | 45 | 2582 | 75 | 3615 | 105 | 4544 | 133 | |
