Gaso, T100-2 (101T-4H), Triplex, Plunger Pump
- 101 horsepower 4 1/2" stroke horizontal triplex single acting plunger pump
- Pump speeds up to 400 RPM
- Multiple accessory gear reduction unit ratios
- Available in three fluid end materials
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1¼" |
| Maximum Plunger Diameter: | 1⅝" |
| Stroke length: | 4½" |
| Maximum Working Pressure: | 5,378 PSI |
| Rod/Piston Load: | 6600lb |
| Gallons per Minute: | 48.5 |
| Barrels per Day: | 1663 |
| Brake Horse Power: | 100.0 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 400 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T100-2 101T-4H | 1.625 | 2.0739 | 4.156 | 0.1212 | 3182 | 208 | 6 | 623 | 18 | 1039 | 30 | 1455 | 42 | 1662 | 48 |
| 1.500 | 1.7671 | 3.541 | 0.1033 | 3735 | 177 | 5 | 531 | 15 | 885 | 26 | 1239 | 36 | 1416 | 41 | |
| 1.375 | 1.4849 | 2.975 | 0.0868 | 4445 | 149 | 4 | 446 | 13 | 744 | 22 | 1041 | 30 | 1190 | 35 | |
| 1.250 | 1.2272 | 2.459 | 0.0717 | 5378 | 123 | 4 | 369 | 11 | 615 | 18 | 861 | 25 | 984 | 29 | |
- Cast iron power frame
- Ductile iron connecting rods
- Alloy steel crosshead pins
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Rated rod load is 6600 lbs.
