Gaso, T100-3 (101T-4M), Triplex, Plunger Pump
- 101 horsepower 4 1/2" stroke horizontal triplex single acting plunger pump
- Pump speeds up to 400 RPM
- Multiple accessory gear reduction unit ratios
- Available in three fluid end materials
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1¾" |
| Maximum Plunger Diameter: | 2½" |
| Stroke length: | 4½" |
| Maximum Working Pressure: | 2,744 PSI |
| Rod/Piston Load: | 6600lb |
| Gallons per Minute: | 114.8 |
| Barrels per Day: | 3936 |
| Brake Horse Power: | 100.0 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 400 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T100-3 101T-4M | 2.500 | 4.9087 | 9.836 | 0.2869 | 1345 | 492 | 14 | 1475 | 43 | 2459 | 72 | 3443 | 100 | 3934 | 115 |
| 2.375 | 4.4301 | 8.877 | 0.2589 | 1490 | 444 | 13 | 1332 | 39 | 2219 | 65 | 3107 | 91 | 3551 | 104 | |
| 2.250 | 3.9761 | 7.967 | 0.2324 | 1660 | 398 | 12 | 1195 | 35 | 1992 | 58 | 2788 | 81 | 3187 | 93 | |
| 2.125 | 3.5466 | 7.106 | 0.2073 | 1861 | 355 | 10 | 1066 | 31 | 1777 | 52 | 2487 | 73 | 2843 | 83 | |
| 2.000 | 3.1416 | 6.295 | 0.1836 | 2101 | 315 | 9 | 944 | 28 | 1574 | 46 | 2203 | 64 | 2518 | 73 | |
| 1.875 | 2.7612 | 5.533 | 0.1614 | 2390 | 277 | 8 | 830 | 24 | 1383 | 40 | 1936 | 56 | 2213 | 65 | |
| 1.750 | 2.4053 | 4.819 | 0.1406 | 2744 | 241 | 7 | 723 | 21 | 1205 | 35 | 1687 | 49 | 1928 | 56 | |
- Cast iron power frame
- Ductile iron connecting rods
- Alloy steel crosshead pins
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Rated rod load is 6600 lbs.
