Wheatley, T365-AL (59T-3L), Triplex, Plunger Pump
- 59 horsepower 3 1/2" stroke horizontal triplex single acting plunger pump
- Available in four different fluid end materials
- Pump speeds up to 420 RPM
- Multiple accessory gear reduction unit ratios
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2½" |
| Maximum Plunger Diameter: | 3" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 970 PSI |
| Rod/Piston Load: | 4760lb |
| Gallons per Minute: | 134.9 |
| Barrels per Day: | 4625 |
| Brake Horse Power: | 59.0 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 420 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T365-AL 59T-3L | 3.000 | 7.0686 | 11.016 | 0.3213 | 673 | 551 | 16 | 1652 | 48 | 2754 | 80 | 3856 | 112 | 4627 | 135 |
| 2.875 | 6.4918 | 10.117 | 0.2951 | 733 | 506 | 15 | 1518 | 44 | 2529 | 74 | 3541 | 103 | 4249 | 124 | |
| 2.750 | 5.9396 | 9.256 | 0.2700 | 801 | 463 | 13 | 1389 | 40 | 2314 | 67 | 3240 | 94 | 3888 | 113 | |
| 2.625 | 5.4119 | 8.434 | 0.2460 | 880 | 422 | 12 | 1265 | 37 | 2109 | 61 | 2952 | 86 | 3542 | 103 | |
| 2.500 | 4.9087 | 7.650 | 0.2231 | 970 | 382 | 11 | 1148 | 33 | 1913 | 56 | 2678 | 78 | 3213 | 94 | |
- Cast iron power frame
- Ductile Iron Crankshaft
- Heavy-duty roller crankshaft bearings
- Bi-Metal crankpin bearings
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves Â
