Wheatley, HP125-AM (110Q-3M), Quintuplex, Plunger Pump
Pumps in this series
HP125-AL (110Q-3L)HP125-AM (110Q-3M)
HP125-H (110Q-H)
HP125-M
HP125-MS (110Q-3MS)
- 110 horsepower 3 1/2" stroke horizontal quintuplex single acting plunger pump
- Available in four fluid end materials
- Pump speeds up to 540 RPM
- Multiple accessory gear reduction unit ratios
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 1⅝" |
| Maximum Plunger Diameter: | 2½" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 2,295 PSI |
| Rod/Piston Load: | 4760lb |
| Gallons per Minute: | 163.6 |
| Barrels per Day: | 5609 |
| Brake Horse Power: | 110.0 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 440 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP125-AM 110Q-3M | 2.500 | 4.9087 | 12.750 | 0.3719 | 970 | 637 | 19 | 1913 | 56 | 3188 | 93 | 4463 | 130 | 5610 | 164 |
| 2.375 | 4.4301 | 11.507 | 0.3356 | 1074 | 575 | 17 | 1726 | 50 | 2877 | 84 | 4027 | 117 | 5063 | 148 | |
| 2.250 | 3.9761 | 10.327 | 0.3012 | 1197 | 516 | 15 | 1549 | 45 | 2582 | 75 | 3615 | 105 | 4544 | 133 | |
| 2.125 | 3.5466 | 9.212 | 0.2687 | 1342 | 461 | 13 | 1382 | 40 | 2303 | 67 | 3224 | 94 | 4053 | 118 | |
| 2.000 | 3.1416 | 8.160 | 0.2380 | 1515 | 408 | 12 | 1224 | 36 | 2040 | 59 | 2856 | 83 | 3590 | 105 | |
| 1.875 | 2.7612 | 7.172 | 0.2092 | 1724 | 359 | 10 | 1076 | 31 | 1793 | 52 | 2510 | 73 | 3156 | 92 | |
| 1.750 | 2.4053 | 6.247 | 0.1822 | 1979 | 312 | 9 | 937 | 27 | 1562 | 46 | 2187 | 64 | 2749 | 80 | |
| 1.625 | 2.0739 | 5.387 | 0.1571 | 2295 | 269 | 8 | 808 | 24 | 1347 | 39 | 1885 | 55 | 2370 | 69 | |
- Cast iron power frame
- Ductile Iron Crankshaft
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Cast iron crossheads with upper/lower oil grooves
- Internal pressure lubrication
- Ductile iron connecting rods
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Rated rod load is 5090 lbs.
- Plungers - Solid Ceramic, or Tungsten coated Â
